C10 HD Installation Manual Section 5: System Administration | Page 5-45
There are three (?6C;5H)1<<H options, defining how a GPI triggers a softkey light: If ?<<?F(F9C38 is selected, the
t
ally is triggered simply by pressing the softkey – useful where there is no external tally back to the button; If ?<<?F
% is selected, the corresponding GPI input is used to light the softkey button – useful for confidence monitoring of fader
starts and similar external machine control. If ?<<?F%$ is selected, the GPI output (‘GPO’) triggers the light – useful
if the GPI can also be triggered by something other than the softkey.
‰
Once you have programmed the GPI output and input, press the 335@C?>697 box to confirm your choices, or
press 1>35<.
‰ If you want to control a console function that is not currently available in the (5<53C D>3C9?> list (shown
o
pposite), import it by finding the appropriate entry in the D>3C9?>B file in the D>3C9?> !9BCB directory on the
console’s hard disk, then copying that line into the %$<BC file found in the same directory, and restarting the console.
Note that you should of course make a backup of any file before editing, using any computer on the console’s network
(see Section 4 for details).
The entries in the %$<BC file follow the format:
Function, min, max, offset, list name, description
For example, to add the channel compressor in/out function:
Comp In, 257, 352, -256, Channel Comp, Chan Compressor In/out
Note: For all channel-based functions, the min, max, and offset values should be 256, 352, and -256 respectively, or
they will not work correctly. Also, the function name at the start of each line should be entered exactly as the Functions
file states, but you may choose the list name and description.
All other functions use min and max values as found in the D>3C9?>B file, with an offset of 0, eg:
ASG On, 0, 8, 0, ASG On, ASG On/off
It is a good idea to limit the %$<BC file to only the essential functions, as this is loaded at bootup, and the more functions
it has will increase the console’s boot time.
