Sony CBK-HD01 - Locations of Main Mechanical Parts

1-3
PDW-700/V1 (E)
1-1-2. Locations of Main Mechanical Parts
1 CCD unit
2 Filter knob
3 LCD Hinge assembly
4 LCD back light
5 Fan motor (exhaust)
6 Fan motor (drive)
7 Loader assembly
8 Cleaner assembly
9 Loading motor assembly
!/ Drive sub assembly
!- Optical block assembly
!= Seek motor assembly
![ Spindle motor
7
2
1
4
5
3
6
9
![
8
!/
!-
!=
