6-5
PDW-700V1 (E)
6-4-1. Display Method and Reset Methods
Refer to “4-9. SERVICE Menu” for the display of the SERVICE menu.
Reset Methods
1. Display the SERVICE menu. (Refer to “4-9. SERVICE Menu” .)
(TOP MENU is displayed on the viewfinder screen.)
2. Select “SERVICE” from the TOP MENU and press the MENU knob.
3. Rotate the MENU knob to scroll the screen up to HOURS METER 2, and press the knob.
4. Rotate the MENU knob to move the cursor onto RESET METER , and press the knob. Move to the
RESET METER screen.
5. Rotate the MENU knob to move the cursor to the desired hours meter.
6. Press the MENU knob. The accumulated time of the selected hours meter is reset.
RESET METER ESC
RESET OPERATION HOURS
RESET SPINDLE RUN HOURS
RESET LASER PARAMETER
RESET LOADING COUNTER
RESET SEEK RUN HOURS
RESET ALL METERS
Resets the power-on hours.
Resets the spindle rotation time.
Resets the light output counter value for the optical head.
Resets the number of times the disc has been loaded.
Resets the seek operation time for the optical head.
Resets all the hour meters.
6-4. Digital Hours Meter
The hours meter has six types of display mode. The operation hours or operation count of the PDW-700
can be accumulated for each mode and displayed on the viewfinder.
The hours meter can be reset as desired.
Use the hours meter as a reference for periodic inspection.
The display can also be checked on the HOURS METER page of the DIAGNOSIS menu (Cannot be reset
in the DIAGNOSIS menu). Display and reset are carried out by using the HOURS METER 2 page in the
SERVICE menu.
Description of HOURS METER 2 page (SERVICE menu)
For the description of the HOURS METER 2 page of the SERVICE menu, refer to Section 4 “4-9. Service
Menu”.
