4-100
PDW-700/V1 (E)
4-10-26. UPLOAD TO EEPROM
This menu allows you to update the EEPROM (IC4)
information backed up on the SE-857 board when only IC4
is replaced.
n
When replacing the SE-857 board, remove the EEPROM
(IC4) from the board, and then mount it on the new board.
This menu is not necessary.
Execute this menu only when IC4 is replaced solely.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [OTHERS]
→ [MEMORY SUPPORT]
→ [UPLOAD TO EEPROM]
1. A confirmation screen appears.
2. Select “YES” by turning the MENU knob, and press
the MENU knob.
The result appears.
If failed:
The following screen appears.
UPLOAD TO EEPROM
FLASH >>> EEPROM
LOAD BACKUP DATA.
ARE YOU SURE?
*YES
NO
UPLOAD TO EEPROM
FLASH >>> EEPROM
LOAD BACKUP DATA.
LOADING...COMPLETED
UPLOAD TO EEPROM
FLASH >>> EEPROM
LOAD BACKUP DATA.
LOADING...FAILED
4-10-23. VERSION
This menu displays the version of the optical drive.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [OTHERS]
→ [VERSION]
4-10-24. SERIAL NO
This menu displays the serial number of the optical drive.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [OTHERS]
→ [SERIAL NO]
4-10-25. CLEAR MEDIA LOG
This menu allows you to delete the log of media.
(Refer to “8-6. Cleaning Media Log” for details.)
n
Once deleted, the deleted log cannot be restored.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [OTHERS]
→ [CLEAR MEDIA LOG]
VERSION
VER : 1.20
BOOT: 1.00 DSP : 1.02
SYS : 1.20 PLD1: 1.10
SERIAL NO
NO: 0000106
