3-4
PDW-700/V1 (E)
Sub Code
n
Any number of the following is applicable for “X” in the sub codes below, showing an operation status
where the error is detected.
Example) Error 0X (X27)
X27→827: Laser current of optical block assembly is abnormal (zero or excessive) “during
horizontal move of unloading”.
Example) Error 5X (X0B)
X0B→80B: Address cannot be read from the disc in optical block assembly “during horizontal
move of unloading”.
0: Operation cannot be identified or no need to be identified.
1: During loading
2: During vertical move of loading
3: Disc is not rotating
4: Seeking
5: Reading
6: Writing
7: Standby state
8: During horizontal move of unloading
9: During vertical move of unloading
A: During disc removal
B: During lens cleaning or device checking
C, D: (Not used)
E: During startup adjustment of optical block assembly
F: During power-on initialization of optical block assembly SA actuator
3-2-3. Error 20
When errors related to loader assembly are detected, the following error codes are displayed.
Main Sub Time data
Maintenance
Drive Description
code code display logger logger
20 018 ← OOAn abnormal current of the loading motor is detected.
111 ← OOHorizontal move of loading did not end within the predetermined time.
117 ← OODisplacement of cartridge is detected in the loader during horizontal move of
loading.
118 ← OOAn abnormal current of the loading motor is detected during horizontal move
of loading.
211 ← OOVertical move of loading did not end within the predetermined time.
213 ← OOCartridge cannot be detected after loading.
217 ← OODisplacement of cartridge is detected in the loader during vertical move of loading.
218 ← OOAn abnormal current of the loading motor is detected during vertical move of
loading.
811 ← OOEjection operation did not end within the predetermined time.
818 ← OOAn abnormal current of the loading motor is detected during the ejection
operation.
911 ← OOUnchucking operation did not end within the predetermined time.
918 ← OOAn abnormal current of the loading motor is detected during the unchucking
operation.
