Sony CBK-HD01 - MAINTENANCE Menu

4-38
PDW-700/V1 (E)
4-6. MAINTENANCE Menu
n
When the range of setting is surrounded by parenthesis ( ) in the setting column, the setup value is the
relative value. The range of setting in parenthesis ( ) can be different from what shown in the manual
depending on the setting in the layer lower than this menu.
WHITE SHADING Display (Adjusting white shading)
Item Setting Function
WHT SHAD CH SEL R/G/B/TEST
*
Selects the channel of shading correction
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST OUT
connector
R WHT H SAW (_99 to 99) Adjusts the H SAW white shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
n
It cannot be changed during the service mode.
R WHT H PARA (_99 to 99) Adjusts the H PARA white shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
n
It cannot be changed during the service mode.
R WHT V SAW (_99 to 99) Adjusts the V SAW white shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
n
It cannot be changed during the service mode.
R WHT V PARA (_99 to 99) Adjusts the V PARA white shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
n
It cannot be changed during the service mode.
WHITE SAW/PARA OFF/ON Turns ON/OFF the white shading SAW/PARA compensation
* : When TEST is set, the channels switch in relation with TEST OUT SELECT.
M01 WHITE SHADING TOP
WHT SHAD CH SEL : R
TEST OUT SELECT : VBS
R WHT H SAW : 0
R WHT H PARA : 0
R WHT V SAW : 0
R WHT V PARA : 0
WHITE SAW/PARA : ON
