4-39
PDW-700/V1 (E)
BLACK SHADING Display (Adjusting black shading)
Item Setting Function
BLK SHAD CH SEL R/G/B/TEST
*
Selects the channel of black shading correction
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST OUT
connector
R BLK H SAW (_99 to 99) Adjusts the H SAW black shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
R BLK H PARA (_99 to 99) Adjusts the H PARA black shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
R BLK V SAW (_99 to 99) Adjusts the V SAW black shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
R BLK V PARA (_99 to 99) Adjusts the V PARA black shading correction
(R/G/B) The R, G and B displays are switched in accordance with the
channel selection implemented by the above SHADING CH
SEL
BLACK SAW/PARA OFF/ON Turns ON/OFF the black shading SAW/PARA compensation
MASTER BLACK (_99 to 99) Adjusts the master black level (All of the R, G and B signal
black levels are adjusted)
MASTER GAIN (TMP) _6/_3/0/3/6/9/12/18/ Sets the temporary master gain
24/30/36/42 dB
* : When TEST is set, the channels switch in relation with TEST OUT SELECT.
M02 BLACK SHADING TOP
BLK SHAD CH SEL : R
TEST OUT SELECT : VBS
R BLK H SAW : 0
R BLK H PARA : 0
R BLK V SAW : 0
R BLK V PARA : 0
BLACK SAW/PARA : ON
MASTER BLACK : 0
MASTER GAIN(TMP): 0dB
