4-96
PDW-700/V1 (E)
4. Insert the alignment disc.
5. Press the MENU knob.
The result appears.
If failed:
The following screen appears.
Perform optical drive alignment. (Refer to Section 8.)
SKEW
CHECKING...OK
SKEW
CHECKING...ERROR
4-10-16. SKEW
This menu allows you to check the skew.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [CHECK]
→ [SKEW]
1. A confirmation screen appears.
2. Select “YES” by turning the MENU knob, and press
the MENU knob.
A warm-up screen appears.
n
If five minutes has already passed since power ON,
this screen appears just for a moment.
If the power has been supplied to the unit for over five
minutes, you can select YES and proceed to the next
step even after you turn off the power and then turn it
back on.
3. A confirmation screen appears when “0000 SEC” is
displayed.
SKEW
CHECK START?
*YES
NO
SKEW
WARMING UP...
REMAINED 0299 SEC
ARE YOU PASS?
*YES
NO
SKEW
INSERT ALIGNMENT DISC
PFD23A-RS
To Next Page
