4-93
PDW-700/V1 (E)
If failed:
The following screen appears.
AUTO TEST
CHECKING...ERROR
4-10-11. FOCUS ACTUATOR
This menu allows you to check the focus of the 2-axis
actuator.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [CHECK]
→ [OPTICAL BLOCK]
→ [FOCUS ACTUATOR]
1. A confirmation screen appears.
2. Select “YES” by turning the MENU knob, and press
the MENU knob.
Check that the 2-axis actuator moves several times.
. If the actuator does not move or its movement is not
smooth, the harness may be connected improperly or
the optical block may be defective.
The result appears.
If failed:
The following screen appears.
FOCUS ACTUATOR
CHECK START?
*YES
NO
FOCUS ACTUATOR
CHECKING...OK
FOCUS ACTUATOR
CHECKING...ERROR
To Next Page
