4-4
PDW-700/V1 (E)
4-4. OPERATION Menu
n
When the range of setting is surrounded by parenthesis ( ) in the setting column, the setup value is the
relative value. The range of setting in parenthesis ( ) can be different from what shown in the manual
depending on the setting in the layer lower than this menu.
OUTPUT 1 Display (Setting the Output Signal)
Item Setting Function
SDI OUT 1 SELECT OFF/HDSDI/SDSDI Selects the output signal from the SDI OUT 1 connector
OFF : No output signal
HDSDI : HD SDI signal
SDSDI : SD SDI signal
SDI OUT 2 SELECT OFF/HDSDI/SDSDI Selects the output signal from the SDI OUT 2 connector
OFF : No output signal
HDSDI : HD SDI signal
SDSDI : SD SDI signal
SDI OUT 2 SUPER OFF/ON Turns ON/OFF the superimposed information output
from the SDI OUT 2 connector
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
(When R/G/B is selected, turning the power ON/OFF
changes the setting to Y)
TEST OUT SUPER OFF/ON Turns ON/OFF the superimposed information output
from the TEST OUT connector
m
• When R/G/B is selected, turning the power of the unit off and on changes the setting to Y.
• When TEST OUT SELECT is set to Y/R/G/B, the character information is displayed regardless of the
setting. The character information can be hidden by switching this item from ON to OFF while the
character information is displayed. (The view finder is also hidden.)
• When TEST OUT SELECT is set to LCD, the character information is displayed or hidden according
to the display mode selected with the DISPSEL/EXPAND button.
O01 OUTPUT1 TOP
SDI OUT1 SELECT : OFF
SDI OUT2 SELECT : OFF
SDI OUT2 SUPER : OFF
TEST OUT SELECT : VBS
TEST OUT SUPER : OFF
