4-14. Adjusting Battery End Detection
Voltage
Before starting adjustment, refer to “9-1. Preparation”.
Devices and tools
For more details, refer to “1-10-2. Measuring Equipment”.
. Rated voltage power source (one that can output at least
10 A)
. Digital voltmeter
. Blank disc
Adjustment Procedure
1. Supply a +12 V voltage to the DC IN connector.
2. Insert a blank disc for recording into the unit, press the
REC START button, and begin recording.
3. Execute POWER A/D ADJUST from the page of
VDR MAINTENANCE of the SERVICE menu.
4. Turn the MENU knob to select “YES” and press the
MENU knob.
5. After adjustment finishes, press down on the MENU
ESCAPE switch.
n
If the message “ADJUST ERROR” appears in the
adjustment result menu, recheck whether a +12 V
voltage is supplied to the DC IN connector and repeat
the adjustment from step 3.
POWER A/D ADJUST
ADJUST START?
YES NO
POWER A/D ADJUST
ADJUST COMPLETE.
ADJ DATA: 0.02[V]
To Next Page
