1-46
PDW-700/V1 (E)
1-10. Service Tools/Measuring Equipment List
1-10-1. Service Tools
The tools and fixtures used in this unit are as follows.
Part No. Name Usage/Note
1 J-6026-110-A Multiburst chart Camera adjustment
2 Commercially Grayscale chart Reflective type (4 : 3, 16 : 9), Camera adjustment
available on market
J-6026-130-B Transparent type (4 : 3), Camera adjustment
J-6394-080-A Transparent type (16 : 9), Camera adjustment
3 J-6029-140-B Pattern box PTB-500 Camera adjustment
4 J-6323-530-A Stop washer fastening tool Stop washer installation
5 J-6570-130-A Alignment disc (PFD23A-RS) Servo adjustment and Skew adjustment
6 J-6325-110-A Bit for torque driver (M1.4) For tightening screw
J-6325-380-A Bit for torque driver (M2) For tightening screw
J-6323-430-A Bit for torque driver (M3) For tightening screw
7 J-6325-400-A Torque driver (3 kg.cm)(0.3N.m) For tightening screw
J-6252-510-A Torque driver (6 kg.cm)(0.6N.m) For tightening screw
J-6252-520-A Torque driver (10 kg.cm)(1.0N.m) For tightening screw
8 3-184-527-01 Cleaning cloth For cleaning
9 3-703-358-08 Parallel pin (2 x 20) For gear replacement, two pins required
!/ 7-432-114-11 Locking compound For preventing screw from being loosened
!- 7-600-000-48 Sony bond (SC608LVZ-180ML) For bonding
!= 9-919-573-01 Cleaning liquid For cleaning
![ Commercially available Memory Stick Saving data (Up to 4.0 GB)
on market
_ Commercially available Flat-blade screwdriver (2.3 mm) Skew adjustment
on market
_ Commercially available Weight (50 to 100 g) Servo adjustment and Skew adjustment
on market
