5-12
PDW-700/V1 (E)
5-4. Special Items to Save
5-4-1. White Gain
Using the ALL FILE
Executing item Status after execution
ALL FILE SAVE All the values of the white gain are saved in the ALL FILE. (Filter A/B/C/D, WHITE BAL A/B)
(FILE menu/ALL FILE page)
ALL FILE LOAD All the values of the white gain are overwritten to the value of ALL FILE.
(FILE menu/ALL FILE page) (Filter A/B/C/D, WHITE BAL A/B)
STORE ALL PRESET The value of the preset white gain specified on the MAINTENANCE menu/PRESET WHT page
(FILE menu/ALL page) is saved as the value of the PRESET layer (identical to the value of the REFERENCE FILE).
CLEAR ALL PRESET All the values of the white gain are overwritten to the factory default value.
(FILE menu/ALL FILE page) (Filter A/B/C/D, WHITE BAL A/B)
The PRESET WHITE R/B GAIN is also changed to the factory default value.
ALL PRESET All the values of the white gain are overwritten to the value of PRESET layer.
(FILE menu/ALL FILE page)
Using the REFERENCE FILE
Executing item Status after execution
REFERENCE STORE The current value of the white gain at the time of execution is saved in REFERENCE FILE.
(FILE menu/REFERENCE page) (When the WHITE BAL switch is A, the saved value is A. When B, the saved value is B.
When PRST, the saved value is PRST.)
If REFERENCE STORE is executed when the WHITE BAL switch is A or B, the preset WHITE
GAIN to be specified in the MAINTENANCE menu/PRESET WHT page is also overwritten to
the value of the saved WHITE GAIN.
REFERENCE CLEAR When the WHITE BAL switch is A at the time of execution, R/B GAIN of A becomes the default
(FILE menu/REFERENCE page) value. When the WHITE BAL switch is B, R/B GAIN of B becomes the factory default value.
PRESET WHITE R. B GAIN becomes the default value irrespective of the BAL switch.
Using the SCENE FILE
Executing item Status after execution
SCENE STORE The current value of the white gain at the time of execution is saved in the SCENE FILE.
(FILE menu/SCENE FILE page) (When the WHITE BAL switch is A, the saved value is A. When B, the saved value is B.
When PRST, the saved value is PRST.)
SCENE RECALL The current value of the WHITE GAIN at the time execution is overwritten to that of the SCENE
(FILE menu/SCENE FILE page) file only when “SCENE WHITE DATA” is set to ON in the FILE menu/REFERENCE page.
(When the WHITE BAL switch is A, the value of A is overwritten. When it is B, the value of B
is overwritten.)
However, the value of the preset WHITE GAIN is retained when the WHITE BAL switch is PRST.
SCENE STANDARD The current value of the WHITE GAIN at the time of execution is overwritten to that of the
(FILE menu/SCENE FILE page) REFERENCE file only when “SCENE WHITE DATA” is set to ON in the FILE menu/
REFERENCE page.
