Sony CBK-HD01 - 4-10. Drive Maintenance

4-85
PDW-700/V1 (E)
4-10-2. TEMPERATURE SENSOR
This menu allows you to check the temperature sensor on
the optical drive.
Menu hierarchy:
[DRIVE MAINTENANCE]
→ [CHECK]
→ [DEVICE]
→ [TEMPERATURE SENSOR]
1. A confirmation screen appears.
2. Select “YES” by turning the MENU knob, and press
the MENU knob.
The current temperature appears.
4-10. Drive Maintenance
Used for the maintenance of the optical drive.
. Use an external monitor for the following items.
“4-10-5. ACCELERATION SENSOR”
“4-10-21. ACCELERATION OFFSET”
. The alignment disc (PFD23A-RS) is required for the
following item.
“4-10-16. SKEW”
4-10-1. Basic Operation on Drive
Maintenance Menus
Enter the drive maintenance menu from the SERVICE
menu. (Refer to “4-9. SERVICE Menu”.)
If a cartridge is remaining inside, it is ejected automatically.
1. Select the “S16 VDR MAINTENANCE” on the
SERVICE menu.
2. Select “DRIVE MAINTE” by turning the MENU
knob, and press the MENU knob.
3. Select “YES” by turning the MENU knob, and press
the MENU knob.
The drive maintenance menu is displayed.
S16 VDR MAINTENANCE TOP
AUDIO A/D ADJUST: EXEC
AUDIO D/A ADJUST: EXEC
AU SIDE VOL ADJ : EXEC
POWER A/D ADJUST: EXEC
DRIVE MAINTE : EXEC
SERVICE SUPPORT : EXEC
DRIVE MAINTENANCE
MAINTENANCE START?
YES NO
DRIVE MAINTENANCE
*CHECK
ADJUST
ERROR LOGGER
OTHERS
TEMPERATURE SENSOR
CHECK START?
*YES
NO
TEMPERATURE SENSOR
36.0[DEG]
