4-55
PDW-700/V1 (E)
M24 UP CONVERTER TOP
UP CON PROCESS : ADPT
UC DETAIL LEVEL : 0
UC CRISPENING : 0
UC DETAIL LIMIT : 0
UC LV DEPEND LVL: 0
UC DTL FREQUENCY: 5.0M
UC DTL H/V RATIO: 0
UP CONVERTER Display (Setting on Upconverter)
Item Setting Function
UP CON PROCESS FIELD/ADPT Selects the conversion source picture when SD is
upconverted to HD
FIELD : Use the field picture
ADPT : Optimize the ratio of conversion from the
frame or field picture
UC DETAIL LEVEL (_99 to 99) Adjusts the sharpness of edge enhancement by the
upconverter
UC CRISPENING (_8 to 7) Sets the amplitude width at which the upconverter
does not emphasize low-amplitude signals
UC DETAIL LIMIT (_99 to 99) Sets the maximum level of edge enhancement by the
upconverter
UC LV DEPEND LVL (_8 to 7) Sets the luminance of edge enhancement by the
upconverter
UC DTL FREQUENCY 3.2M/4.5M/5.0M/4.0M Sets the center frequency and frequency properties of
edge enhancement by the upconverter
3.2M : 3.2 ± 1.1 MHz
4.5M : 4.5 ± 1.4 MHz
5.0M : 5.0 ± 0.7 MHz
4.0M : 4.0 ± 2.0 MHz
UC DTL H/V RATIO (_3 to 4) Sets the horizontal/vertical ratio of edge enhancement
by the upconverter
