4-67
PDW-700/V1 (E)
D06 DEV STATUS TOP
I/O EEPROM LSI
MS :OK CN :OK DCP1:OK
FP :OK DCP :OK DCP2:OK
CN :OK DR :OK DCP3:OK
DCP :OK DCP4:OK
VF :OK FRAM TG :OK
D/A AT :OK
DCP1:OK SCI
DCP2:OK FAN SY :OK
DCP3:OK MB :OK RM :--
ROM VERSION 3 Display (Displaying the ROM version)
Item Setting Function
DSP0 Display only Displays the DVP-45 board’s IC800 version stored in the ROM (IC505, IC506) on the SY-355 board
*
DSP2 Display only Displays the DVP-45 board’s IC801 version stored in the ROM (IC505, IC506) on the SY-355 board
*
PRXA Display only Displays the DVP-45 board’s IC900 version stored in the ROM (IC505, IC506) on the SY-355 board
*
* : Can be upgraded with the firmware package file from MENU.
DEV STATUS Display (Checking the communication function of each device)
Item Display Function
I/O _ I/O : Status display of MS/FP/CN/DCP/VF
MS-86:IC2/FP-157:IC107/CN-3005:IC1/
DCP-44:IC1119/VF(IO in each VF)
OK/NG/__ message is displayed
OK : Normal
NG : Abnormal
__ : The state is not defined
D/A _ D/A : Status display of DCP1/DCP2/DCP3
DCP-44:IC1524/DCP-44:IC1518/DCP-44:IC1525
EEPROM _ EEPROM : Status display of CN/DCP/DR
CN-3005:IC2/DCP-44:IC8/DR-617:IC20
FRAM _ FRAM : Status display of AT
AT-177 : IC308
FAN _ FAN : Status display of MB
LSI _ LSI : Status display of DCP1/DCP2/DCP3/DCP4/TG
DCP-44:IC600/DCP-44:IC800/DCP-44:IC221/
DCP-44:IC1000/TG-260:IC8
SCI _ SCI : Status display of SY/RM
D05 ROM VERSION 3 TOP
DSP0 : x.xx
DSP2 : x.xx
PRXA : x.xx
