PDW-700V1 (E)
Recommended replacement parts
ID Part name Sony part No. Recommended replacement timing
1 Cover BNC (PH3) 3-870-160-01
3 Eye cup kit (RP) A-8319-943-B
4 Wind screen A-1096-362-A
5 Filter unit, optical 1-788-765-11 It can become nebulous (intransparent and whitened) with elapse of time.
Then it will not meet the required characteristics. Replace it as needed.
6 Cover (handle), connector 3-870-237-01
7 Protector 3-870-158-01
8 Cover, headphone jack 3-870-140-01
9 Cover (XLR), drop protection 3-870-246-02
10 Cap ME 3-870-253-02
11 Foot, rubber 3-723-097-01
12 Pad assembly, shoulder A-8279-878-G
13 GEL, MIC 3-854-132-01
14 Tape (A) 3-941-343-01
15 Light connector cover 3-877-892-01
16 Holder lens mount 3-796-982-02
17 Battery connector 1-820-459-21
18 Ring, mount 3-186-442-01 Replace every 5 years.
19 Collar, suspension 3-654-615-02
20 Cover bottom, handle 3-796-975-02
21 VTR start button 3-986-632-02 Replace every about 3 years, or check for deformation and deterioration
(abraded or damaged or lost) from time to time.
Replace it as necessary.
*
* : When the part is replaced, apply the instant adhesive (Loctite 408 or equivalent) to the whole area of the flange from the back side with care not to ooze out
to cosmetic surface.
Check for deformation and deterioration (abraded or damaged or lost) from
time to time.
Replace it as necessary.
Check for deformation and deterioration (abraded or damaged or lost) from
time to time.
Replace it as necessary.
Check for deformation and deterioration (abraded or damaged or lost) from
time to time.
Replace it as necessary.
