2-2
PDW-700/V1 (E)
Connection Diagram
Direct connection of a camcorder (single) to the host PC
Connection of the camcorder to the host PC through the other Network device
To Network
connector
1
1
1
1
1 : Network Cable
(Network) connector
(Network) connector
Network,
Hub, etc
(Network) connector
1 : Network Cable
(Network) connector
To Network connector
1
