O06 ASSIGNABLE SW TOP
ASSIGN SW <1> : OFF
ASSIGN SW <2> : OFF
ASSIGN SW <3> : OFF
ASSIGN SW <4> : OFF
ASSIGN SW <RET> : RET
COLOR TEMP
SW
: T5600
ZOOM SPEED : 20
RETURN VIDEO : OFF
ASSIGNABLE SW Display (Setting the ASSIGN SW)
Item Setting Function
ASSIGN SW 1/3/4/RET OFF Assigns no function
COLOR TEMP SW
FRONT MIC MONO/STEREO Assigns the function to switch stereo and monaural when the stereo
microphone is connected
PICTURE CACHE ON/OFF Assigns the function to execute picture cache recording
SUPER (VFDISP&MENU) Assigns the function to switch whether or not to combine the character
information of the view finder and that of menu with the video signal that is
output from the SDI OUT 2 connector or the TEST OUT connector when
SDI OUT 2 SUPER or TEST OUT SUPER is set to ON in the OUTPUT 1
page of the OPERATION menu
MARKER Assigns the ON/OFF function to display all markers
*1
RE-TAKE
*2
Assigns the function to delete the last recorded clip
ATW Assigns the ON/OFF function of auto-tracing white balance
RETURN VIDEO Assigns the function that displays in the viewfinder the HD-Y (1080i) signal
input to the GENLOCK IN connector
*3
LENS RET Assigns the same function as that of the RET switch on the lens to the switch
REC SWITCH Assigns the REC START (recording start) function to the switch
TURBO SWITCH Assigns the turbo gain function to the switch
ZEBRA Assigns the zebra pattern display function to the switch
FREEZE MIX Assigns the function that mixes a still picture (monochrome) and camera
video (color) (effective for framing shots)
COLOR TEMP SW 3200K Assigns the function to switch the White-balance to 3200K
COLOR TEMP SW 4300K Assigns the function to switch the White-balance to 4300K
COLOR TEMP SW 5600K Assigns the function to switch the White-balance to 5600K
COLOR TEMP SW 6300K Assigns the function to switch the White-balance to 6300K
ELECTRICAL CC Assigns the function that switches between electrical CC filters (3200K/
4300K/5600K/6300K) whenever pushing the switch
The color temperatures of the electrical filter can be changed by the setting
ELECTRICAL CC <A> to <D> of the WHITE FILTER page (The positions to
which the dash marks ----- are set are skipped)
Alternately, color temperatures can be switched in accordance with the
settings A/B/C/D from RM/MSU/RCP when a remote control unit is connected
CC5600K Applies an electrical 5600K filter
ZOOM TELE/WIDE
*4
When using a serial lens, assign the ZOOM TELE setting to ASSIGN 3, and
the WIDE setting to ASSIGN 4
ZOOM WIDE/TELE
*4
When using a serial lens, assign the ZOOM WIDE setting to ASSIGN 3, and
the TELE setting to ASSIGN 4
SHOT MARK1 Assigns the function to record a SHOT MARK 1 essence mark
SHOT MARK2 Assigns the function to record a SHOT MARK 2 essence mark
CLIP FLAG OK Assign the functions that set or clear OK/NG/KEEP flags during
CLIP FLAG NG
recording or playback
CLIP FLAG KEEP
*1 : Even when the MARKER item is set to OFF on the MARKER page of the USER menu, the ASSIGN 1/3/4 switch allows you to display or not to display all
markers.
*2 : Cannot be assigned to the RET button of the lens.
*3 : Even if the RETURN VIDEO item is set to OFF on the GENLOCK page of the MAINTENANCE menu, you can use this switch to display the image of the
return video signal on the viewfinder.
*4 : Only the Assign 3 SEL and Assign 4 SEL screens appear.
