RM0453 Rev 2 1397/1454

RM0453 Debug support (DBG)

1441

38.10.9 ITM CoreSight peripheral identity register 3 (ITM_PIDR3)

Address offset: 0xFEC

Reset value: 0x0000 0000

38.10.10 ITM CoreSight component identity register 0 (ITM_CIDR0)

Address offset: 0xFF0

Reset value: 0x0000 000D

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Res. Res. Res. Res. Res. Res. Res. Res. REVAND[3:0] CMOD[3:0]

rrrrrrrr

Bits 31:8 Reserved, must be kept at reset value.

Bits 7:4 REVAND[3:0]: metal fix version

0x0: No metal fix

Bits 3:0 CMOD[3:0]: customer modified

0x0: No customer modifications

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Res. Res. Res. Res. Res. Res. Res. Res. PREAMBLE[7:0]

rrrrrrrr

Bits 31:8 Reserved, must be kept at reset value.

Bits 7:0 PREAMBLE[7:0]: component ID bits [7:0]

0x0D: Common ID value
