Debug support (DBG) RM0453

1324/1454 RM0453 Rev 2

In the case of a FAULT or WAIT ACK response from the target, the data transfer phase is

canceled, unless overrun detection is enabled: in this case the data is ignored by the target

(in the case of a write), or not driven (in the case of a read).

A line reset must be generated by the host when it is first connected, or following a protocol

error. The line reset consists in 50 or more SWCLK cycles with SWDIO high, followed by

two SWCLK cycles with SWDIO low.

For more details on the Serial-wire debug protocol, refer to the Arm

Debug Interface

Architecture Specification [1].

Note: The SWJ-DP implements SWD protocol version 2.

38.4 Debug port (DP) registers

Both SW-DP and JTAG-DP access the DP registers listed in Table 268: DP register map

and reset values.

The debugger accesses the DP registers as follows:

• Program the A(3:2) field in the DPACC register, if using JTAG, with the register address

within the bank. Program the RnW bit to select a read or write. In the case of a write,

program the DATA field with the write data. If using SWD, the A(3:2) and RnW fields

are part of the packet request word sent to the SW-DP with the APnDP bit reset (see

Table 264). The write data are sent in the data phase.

• To access one of the banked DP registers at address 0x4, the register number must

first be written to the DP_SELECTR register at address 0x8. Any subsequent read or

write to address 0x4 accesses the register corresponding to the content of the

DP_SELECTR register.

Table 265. ACK response

Bit field Name Description

2:0 ACK

– 000: FAULT

– 010: WAIT

– 100: OK

Table 266. Data transfer

Bit field Name Description

31:0 WDATA or RDATA Write or read data

32 Parity Single bit parity of 32 data bits
