RM0453 Rev 2 407/1454
RM0453 General-purpose I/Os (GPIO)
426
10.4.9 GPIOx alternate function low register (GPIOx_AFRL) (x = A to B)
Address offset: Block A: 0x0020
Address offset: Block B: 0x0420
Reset value: 0x0000 0000
10.4.10 GPIOx alternate function high register (GPIOx_AFRH) (x = A to B)
Address offset: Block A: 0x0024
Address offset: Block B: 0x0424
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
AFSEL7[3:0] AFSEL6[3:0] AFSEL5[3:0] AFSEL4[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
AFSEL3[3:0] AFSEL2[3:0] AFSEL1[3:0] AFSEL0[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 AFSEL7[3:0]: Port Px7 alternate function selection
Bits 27:24 AFSEL6[3:0]: Port Px6 alternate function selection
Bits 23:20 AFSEL5[3:0]: Port Px5 alternate function selection
Bits 19:16 AFSEL4[3:0]: Port Px4 alternate function selection
Bits 15:12 AFSEL3[3:0]: Port Px3 alternate function selection
Bits 11:8 AFSEL2[3:0]: Port Px2 alternate function selection
Bits 7:4 AFSEL1[3:0]: Port Px1 alternate function selection
Bits 3:0 AFSEL0[3:0]: Port Px0 alternate function selection
These bits are written by software to configure alternate function I/Os
0x0: AF0 selected
0x1: AF1 selected
0x2: AF2 selected
...
0xE: AF14 selected
0xF: AF15 selected
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
AFSEL15[3:0] AFSEL14[3:0] AFSEL13[3:0] AFSEL12[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
AFSEL11[3:0] AFSEL10[3:0] AFSEL9[3:0] AFSEL8[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 AFSEL15[3:0]: Port Px15 alternate function selection
Bits 27:24 AFSEL14[3:0]: Port Px14 alternate function selection
Bits 23:20 AFSEL13[3:0]: Port Px13 alternate function selection
