ST STM32WL55JC User Manual

RM0453 Rev 2 1401/1454
RM0453 Debug support (DBG)
1441
38.11.1 TPIU supported port size register (TPIU_SSPSR)
Address offset: 0x000
Reset value: 0x0000 000F
38.11.2 TPIU current port size register (TPIU_CSPSR)
Address offset: 0x004
Reset value: 0x0000 0001
38.11.3 TPIU asynchronous clock prescaler register (TPIU_ACPR)
Address offset: 0x010
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PORTSIZE[31:16]
rrrrrr r r r r rrrrrr
1514131211109876543210
PORTSIZE[15:0]
rrrrrr r r r r rrrrrr
Bits 31:0 PORTSIZE[31:0]: supported trace port sizes, from 1 to 32 pins
Bit n-1 when set indicates that port size n is supported.
0x0000 000F: Port sizes 1 to 4 supported
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PORTSIZE[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
PORTSIZE[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 PORTSIZE[31:0]: current trace port size
Bit n-1 when set indicates that the current port size is n pins. The value of n must be within
the range of supported port sizes (1-4). Only one bit can be set, or unpredictable behaviour
may result. This register must be modified only when the formatter is stopped.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. PRESCALER[12:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw
