RM0453 Rev 2 217/1454
RM0453 Sub-GHz radio (SUBGHZ)
217
Refer to Section 2.6 for the register boundary addresses.
0x0742
to
0x0818
Reserved Reserved
0x0819
SUBGHZ_RNGR3 RNDATA[31:24]
Reset value 00000000
0x081A
SUBGHZ_RNGR2 RNDATA[23:16]
Reset value 00000000
0x081B
SUBGHZ_RNGR1 RNDATA[15:8]
Reset value 00000000
0x081C
SUBGHZ_RNGR0 RNDATA[7:0]
Reset value 00000000
0x0820
to
0x08AB
Reserved Reserved
0x08AC
SUBGHZ_RXGAINCR SENSI_ADJUST[5:0]. PMODE[1:0]
Reset value 10010100
0x08B0
to
0x08E6
Reserved Reserved
0x08E7
SUBGHZ_PAOCPR Res. Res. OCP[5:0]
Reset value 011000
0x08E8
to
0x0910
Reserved Reserved
0x0911
SUBGHZ_HSEINTRIMR Res. Res. TRIM[5:0]
Reset value 010010
0x0912
SUBGHZ_HSEOUTTRIMR Res. Res. TRIM[5:0]
Reset value 010010
0x0913
to
0x0915
Reserved Reserved
0x0916
SUBGHZ_SMPSC0R Res. CLKDE Res. Res. Res. Res. Res. Res.
Reset value 0
0x0917
to
0x0919
Reserved Reserved
0x091A
SUBGHZ_PCR Res. CLE CLV[1:0] Res. Res. Res. Res.
Reset value 1 0 1
0x091B
to
0x0920
Reserved Reserved
0x0923
SUBGHZ_SMPSC2R Res. Res. Res. Res. Res. DRV[1:0] Res.
Reset value 1 1
Table 42. SUBGHZ radio register map and reset values (continued)
Offset Register 76543210
