16.6.4 EXTI pending register (EXTI_PR1)
Address offset: 0x00C
Reset value: 0x0000 0000
Contains only register bits for configurable events.
Bits 31:23 Reserved, must be kept at reset value.
Bit 22 SWI22: Software interrupt on line 22
A software interrupt is generated independently from the setting in EXTI_RTSR and
EXTI_FTSR. This bit always returns 0 when read.
0: Writing 0 has no effect.
1: Writing 1 to this bit triggers an event on line 22.
This bit is automatically cleared by hardware.
Bit 21 SWI21: Software interrupt on line 21
Bits 20:17 Reserved, must be kept at reset value.
Bit 16 SWI16: Software interrupt on line 16
Bit 15 SWI15: Software interrupt on line 15
Bit 14 SWI14: Software interrupt on line 14
Bit 13 SWI13: Software interrupt on line 13
Bit 12 SWI12: Software interrupt on line 12
Bit 11 SWI11: Software interrupt on line 11
Bit 10 SWI10: Software interrupt on line 10
Bit 9 SWI9: Software interrupt on line 9
Bit 8 SWI8: Software interrupt on line 8
Bit 7 SWI7: Software interrupt on line 7
Bit 6 SWI6: Software interrupt on line 6
Bit 5 SWI5: Software interrupt on line 5
Bit 4 SWI4: Software interrupt on line 4
Bit 3 SWI3: Software interrupt on line 3
Bit 2 SWI2: Software interrupt on line 2
Bit 1 SWI1: Software interrupt on line 1
Bit 0 SWI0: Software interrupt on line 0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. PIF22 PIF21 Res. Res. Res. Res. PIF16
rw rw rw
1514131211109876543210
PIF15 PIF14 PIF13 PIF12 PIF11 PIF10 PIF9 PIF8 PIF7 PIF6 PIF5 PIF4 PIF3 PIF2 PIF1 PIF0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
