Stratasys F770 - Top Covers; Oven Door; Upper Right & Upper Left Side Panels; Rear Panels

Printer Overview Access Doors and Panels
Page 26
© Copyright 2021 Stratasys. All rights reserved.
Figure 2: Access Doors and Panels - Rear View
Top Covers
Allow access to the gantry and head assemblies.
Oven Door
Allows access to the platen, tip wipe assemblies, purge area, and completed parts for removal.
The printer’s camera is also housed within the oven door.
Upper Right & Upper Left Side Panels
The upper right and Upper left side panels provide access to the oven chamber fans.
Rear Panels
The rear panels provides access to the electronics bay.
Rear
Panels
Material
Coil
Tubes
Material
Coil
Boxes
Rear
Top
Panel
Rear
Side
Panels
Material
Ports
