Stratasys F770 - Gantry

Gantry Material Coil Box
Page 34
© Copyright 2021 Stratasys. All rights reserved.
filament key reader chip which interfaces with the filament key to communicate each material
coil box’s material type and the quantity of material within the box. The F770 require two
material coil boxes: one for model material and one for support material.
Figure 10: Material Coil Box and Material Port
Gantry
To access the gantry or the heads, you must first open the side access cover. The side access
cover utilizes a mechanical locking mechanism. The top cover remains locked while the printer
is building and automatically unlocks in tandem with the oven door. The printer cannot resume
building if the side access cover and/or oven door are open.
Support Material
Port
Model Material
Port
Material Coil
Box
