A - 6 DS7708 2D VERTICAL SLOT PRESENTATION SCANDS7708 2D Vertical Slot Scanner Product Reference
Bookland ISBN Format F1h 40h 576 ISBN-10 12-15
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
10h 16 Ignore
12-17
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
F1h 43h
F1h 44h
579
580
n/a
12-24
UPC/EAN/JAN Supplemental
Redundancy
50h 80 10 12-25
Decode UPC/EAN/JAN Supplemental
AIM ID Format
F1h A0h 672 Combined 12-26
UPC Reduced Quiet Zone F8h 05h 09h 1289 Disable 12-28
Transmit UPC-A Check Digit 28h 40 Enable 12-29
Transmit UPC-E Check Digit 29h 41 Enable 12-30
Transmit UPC-E1 Check Digit 2Ah 42 Enable 12-31
UPC-A Preamble 22h 34 System Character 12-32
UPC-E Preamble 23h 35 System Character 12-34
UPC-E1 Preamble 24h 36 System Character 12-36
Convert UPC-E to A 25h 37 Disable 12-38
Convert UPC-E1 to A 26h 38 Disable 12-39
EAN-8/JAN-8 Zero Extend 27h 39 Disable 12-40
UCC Coupon Extended Code 55h 85 Disable 12-41
Coupon Report F1h DAh 730 New Coupon Symbols 12-43
ISSN EAN F1h 69h 617 Disable 12-44
Code 128
Code 128 08h 8 Enable 12-45
Set Length(s) for Code 128 D1h, D2h 209, 210 1 - 55 12-48
GS1-128 (formerly UCC/EAN-128) 0Eh 14 Enable 12-49
ISBT 128 54h 84 Disable 12-50
ISBT Concatenation F1h 41h 577 Disable 12-51
Check ISBT Table F1h 42h 578 Enable 12-53
ISBT Concatenation Redundancy DFh 223 10 12-54
Table A-1 Standard Default Parameters Table (Continued)
Parameter SSI Number
1
Parameter
Number
2
Default
Page
Number
1
SSI number hex values are used for programming via SSI commands.
2
Parameter number decimal values are used for programming via RSM commands.
