Model 100E Instruction Manual APPENDIX A-2: Setup Variables For Serial
I/O, Revision B.3
045150110 Rev B.3 233
Setup Variable Numeric
Units
Default Value Value Range Description
VAC_SAMP_RATIO
3
— 0.53 0.1 to 2 Maximum vacuum
pressure / sample
pressure ratio for valid
sample flow calculation.
SAMP_PRESS_SET “Hg-A 29.92
Warnings:
15 to 35
0 to 100 Sample pressure set point
for pressure compensation
and warning limits.
SAMP_PRESS_SLOPE — 1 0.5 to 1.5 Sample pressure slope
correction factor (adjusted
pressure = measured
pressure x slope).
VAC_PRESS_SET
3
“Hg 6
Warnings:
3 to 10
0 to 100 Vacuum pressure set point
for pressure compensation
and warning limits.
BOX_SET ºC 30
Warnings:
8 to 50
5 to 60 Box temperature warning
limits. Set point is not
used.
PMT_SET ºC 7
Warnings:
2 to 12
0 to 40 PMT temperature set point
and warning limits.
