APPENDIX A-2: Setup Variables For Serial I/O,
Revision B.3
Model 100E Instruction Manual
234 045150110 Rev B.3
Setup Variable Numeric
Units
Default Value Value Range Description
RS232_MODE BitFlag 0,
3
5
19200
0 to 65535 RS-232 COM1 mode flags.
Add values to combine
flags.
1 = quiet mode
2 = computer mode
4 = enable security
8 = enable iChip support
(1)
16 = enable Hessen
protocol
32 = enable multi-drop
64 = enable modem
128 = ignore RS-232 line
errors
256 = disable XON / XOFF
support
512 = disable hardware
FIFOs
1024 = enable RS-485
mode
4096 = enable command
prompt
(1)
Must power-cycle
instrument for these
options to take effect.
BAUD_RATE — 300,
1200,
2400,
4800,
9600,
19200,
38400,
57600,
115200
RS-232 COM1 baud rate.
Enclose value in double
quotes (“) when setting
from the RS-232
interface.
MODEM_INIT — “AT Y0 &D0 &H0
&I0 S0=2 &B0 &N6
&M0 E0 Q1 &W0”
Any character
in the allowed
character set.
Up to 100
characters long.
RS-232 COM1 modem
initialization string. Sent
verbatim plus carriage
return to modem on
power up or manually.
Enclose value in double
quotes (“) when setting
from the RS-232
interface.
RS232_MODE2 BitFlag 0 0 to 65535 RS-232 COM2 mode flags.
(Same settings as
RS232_MODE.)
