Model 100E Instruction Manual APPENDIX A-2: Setup Variables For Serial
I/O, Revision B.3
045150110 Rev B.3 235
Setup Variable Numeric
Units
Default Value Value Range Description
BAUD_RATE2 — 19200 300,
1200,
2400,
4800,
9600,
19200,
38400,
57600,
115200
RS-232 COM2 baud rate.
Enclose value in double
quotes (“) when setting
from the RS-232
interface.
MODEM_INIT2 — “AT Y0 &D0 &H0
&I0 S0=2 &B0 &N6
&M0 E0 Q1 &W0”
Any character
in the allowed
character set.
Up to 100
characters long.
RS-232 COM2 modem
initialization string. Sent
verbatim plus carriage
return to modem on
power up or manually.
Enclose value in double
quotes (“) when setting
from the RS-232
interface.
RS232_PASS Password 940331 0 to 999999 RS-232 log on password.
MACHINE_ID ID 100 0 to 9999 Unique ID number for
instrument.
SO2_GAS_ID ID 110 0 to 999 Unique ID number for SO
2
gas.
GATEWAY_IP_ADDR
7
— “000.000.000.000” Any string of
digits and
decimal points.
Gateway IP address.
INST_IP_ADDRESS
7
— “000.000.000.000” Any string of
digits and
decimal points.
Instrument IP address.
INST_SUBNET_MASK
7
— “255.255. 255.0” Any string of
digits and
decimal points.
Instrument subnet mask.
INST_TCP_PORT
7
— 3000 1024 to 65535 Instrument TCP port.
COMMAND_PROMPT — “Cmd> ” Any character
in the allowed
character set.
Up to 100
characters long.
RS-232 interface
command prompt.
Displayed only if enabled
with RS232_MODE
variable. Enclose value in
double quotes (“) when
setting from the RS-232
interface.
