Model 100E Instruction Manual APPENDIX A-2: Setup Variables For Serial
I/O, Revision B.3
045150110 Rev B.3 237
Setup Variable Numeric
Units
Default Value Value Range Description
IZS_PROP
1
1/ºC 1 (prop. band = 1
ºC)
0 to 10 IZS temperature PID
proportional coefficient.
IZS_INTEG
1
— 0.03 0 to 10 IZS temperature PID
integral coefficient.
IZS_DERIV
1
— 0 0 to 10 IZS temperature PID
derivative coefficient.
HVPS_SET Volts 650,
550
3
Warnings:
400 to 900,
400 to 700
3
0 to 2000 High voltage power supply
warning limits. Set point is
not used.
DETECTOR_LIMIT mV 1000 Warnings:
600 to 4995
0 to 5000 UV lamp and PMT detector
warning limits. Set point is
not used.
SERIAL_NUMBER —
“00000000 ”
Any character
in the allowed
character set.
Up to 100
characters long.
Unique serial number for
instrument. Enclose value
in double quotes (“) when
setting from the RS-232
interface.
DISP_INTENSITY — HIGH HIGH,
MED,
LOW,
DIM
Front panel display
intensity. Enclose value in
double quotes (“) when
setting from the RS-232
interface.
I2C_RESET_ENABLE — ON OFF, ON I
2
C bus automatic reset
enable.
