Safety guard 103
21 Safety guard
The machine can be equipped with various safety guards.
Depending on the safety guard in place, the operation and functions of the machine will
differ.
21.1 Safety guard – light barrier
B
Machine
C Safety guard
D Light barrier
If there is a light barrier in place as a safety guard, the functions are triggered using the
illuminated START button.
The green START symbol appears on the touchscreen of the operating
panel when the machine is ready to start.
The START illuminated button lights up when the machine is ready to start.
Pressing the illuminated START button carries out the selected function.
B
C
D
