Technical Data 23
8 Technical Data
8.1 Connection values
8.2 Operating conditions
Ideal printing results are achieved under the following conditions:
8.3 Weight
The machines are available in several versions.
See also Chapter 8.4 "Versions" on page 24.
All versions are the same weight.
The machines can be optionally fitted with a pad cleaning system.
A pad cleaning system will increase the overall weight of the machine.
Electrical connection
Operating voltage: 230 V AC – 50/60 Hz
Power consumption: approx. 0.5 kW
Control voltage: 24 V DC
Ambient conditions
Temperature: 20°C
68°F
Humidity: 50% – 70%
Equipment Weight
Without pad cleaning approx. 130 kg
approx. 290 lbs
With pad cleaning approx. 140 kg
approx. 310 lbs
