Transtech SealCup Express - Unfasten Ink Cup

Cliché Assembly (EU) 65
15.2.3 Unfasten ink cup
Pull out the lock pin D from the ink cup
fixing and pull the lever down.
When you let go, stop the lock pin in the
lower position.
The ink cup holder
E raises and releases
the ink cup.
D
E
