Pad Assembly Screw Fastening 45
13.3.1 Pad removal
Unscrewing the pad coupling
Unscrew the clamping screw
B belonging to the
pad coupling.
Pull out the pad coupling complete with the pad
towards the front.
Unscrewing the pad
The pad is fastened to the pad coupling with a
screw
C.
Loosen the screw and remove the pad.
B
C
