94 Express Liner Ink Cup
19.5.2 Inserting the doctor ring
Position the ink container with the opening
facing upwards. There is a radial groove
B
located on the outer edge to accommodate
the doctor ring.
Place the doctor ring
C into the radial
groove
B from above.
In this case, the sharp ground blade edge
will be located on the top.
Carefully press the doctor ring into the
radial groove.
The illustration shows the ink container with
doctor ring
C inserted.
B
B
C
C
