Adding a plane
feature example
Displacement offsets the plane in either the positive or negative direction
along the plane normal (Z-axis of the plane feature).
Deselect the checkbox for the Elbow and the Tool Flange so they do not
trigger the safety plane. The Elbow can remain checked as needed by your
application.
The unrestricted tool flange can cross a safety plane, even when no tool is
defined.
If no tool is added, a warning on the Tool Position button prompts you to
correctly define the tool.
When working with an unrestricted tool flange and a defined tool, it is
ensured that the dangerous part of the tool can't go above and/or beyond
certain area. The unrestricted tool flange can be used for any application
where safety planes are needed, like Welding or Assembly.
User Manual 151 UR16e
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
