8.3. Mounting
Description Specifying the mounting of the Robot arm serves two purposes:
1. Making the Robot arm appear correctly on screen.
2. Telling the controller about the direction of gravity.
An advanced dynamics model gives the Robot arm smooth and precise
motions, as well as allows the Robot arm to hold itself in Freedrive Mode.
For this reason, it is important to mount the Robot arm correctly.
WARNING
Failure to mount the Robot’s arm correctly may result in
frequent robot stops, and/or the Robot arm will move when
pressing the Freedrive button.
If the Robot arm is mounted on a flat table or floor, no change is needed on
this screen.
However, if the Robot arm is ceiling mounted, wall mounted, or mounted
at an angle, this needs to be adjusted using the buttons.
The buttons on the right side of the screen are for setting the angle of the
Robot arm’s mounting. The top three right side buttons set the angle to
ceiling (180
∘
), wall (90
∘
), floor (0
∘
). The Tilt buttons set an arbitrary angle.
UR16e 288 User Manual
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
