NOTICE
The end effector is not protected by the UR safety system. The functioning of the
end effector and/or connection cable is not monitored
2.2.2. Stop Categories
Depending on the circumstances, the robot can initiate three types of stop categories
defined according to IEC 60204-1. These categories are defined in the following table.
Stop
Category
Description
0 Stop the robot by immediate removal of power.
1
Stop the robot in an orderly, controlled manner. Power is removed once the
robot is stopped.
2
*Stop the robot with power available to the drives, while maintaining the
trajectory. Drive power is maintained after the robot is stopped.
*Universal Robots robots’ Category 2 stops are further described as SS1 or as SS2 type
stops according to IEC 61800-5-2.
2.2.3. Configurable Safety Functions
Universal Robots robot safety functions, as listed in the table below, are in the robot but are
meant to control the robot system i.e. the robot with its attached tool/end effector. The robot
safety functions are used to reduce robot system risks determined by the risk assessment.
Positions and speeds are relative to the base of the robot.
Safety
Function
Description
Joint
Position
Limit
Sets upper and lower limits for the allowed joint positions.
Joint Speed
Limit
Sets an upper limit for joint speed.
Safety
Planes
Defines planes, in space, that limit robot position. Safety planes limit either
the tool/end effector alone or both the tool/end effector and the elbow.
Tool
Orientation
Defines allowable orientation limits for the tool.
