8-7
PWBs ＞ Description for PWB
[CONFIDENTIAL]
12 +24V0 I DC24V Power input
13 +24V0 I DC24V Power input
YC2 1 EECLK O DC0V/3.3V Clock signal
2 GND - - Ground
3 EESIO I/O DC0V/3.3V (pulse) Communication data
4 ERASER O DC0V/3.3V Cleaning lamp: On/Off
5 +3.3V3_F2 O DC3.3V Power source
6 TSENS I Analog Toner sensor output signal
7 SBMDIR O DC0V/3.3V Eject motor: On/Off
8 WTSENS I Analog WTS output signal
9 SBMENBLN O DC0V/3.3V Enable signal
10 WTLED O DC0V/3.3V LED: On/Off
11 SBMSTEP O DC0V/3.3V (pulse) Clock signal
12 MPFSENS I DC0V/3.3V MP paper sensor: On/Off
13 SBMMODE O DC0V/3.3V Mode signal
14 +3.3V1_PWM_F2 O DC3.3V Power source
15 TMOT O DC0V/3.3V Toner motor: On/Off
16 LFANN O DC0V/3.3V Center fan motor: On/Off
17 FUDR O DC0V/3.3V Feedshift solenoid: On/Off
18 ENVMOT O DC0V/3.3V Fuser pressure release motor: On/Off
19 FDDR O DC0V/3.3V Feedshift solenoid: On/Off
20 DUJAMSEN1N I DC0V/3.3V Duplex sensor: On/Off
21 REGSEN2 I DC0V/3.3V Registration sensor 2: On/Off
22 REARSWN I DC0V/3.3V Rear cover switch: On/Off
YC4 1 MMOTCW O DC0V/5V Main motor drive shift signal
2 MMOTRDYN I DC0V/3.3V Main motor ready signal
3 MMOTCLKN O DC0V/5V (pulse) Main motor clock signal
4 MMOTONN O DC0V/5V Main motor: On/Off
5 GND - - Ground
6*1 +24V3_IL O DC24V Power source
7*1 DMOTCW O DC0V/5V Drum motor rotation direction
8*1 DMOTRDYN I DC0V/3.3V Drum motor ready signal
9*1 DMOTCLKN O DC0V/5V (pulse) Drum motor clock signal
10*1 DMOTONN O DC0V/5V Drum motor: On/Off
11*1 GND - - Ground
12*1 +24V3_IL O DC24V Power source
YC5 1 +24V3_IL O DC24V Power source
2 DLPCLN O DC0V/3.3V Developer clutch: On/Off
3 +24V3_IL O DC24V Power source
4 FEEDCLN O DC0V/24V Paper feed clutch: On/Off
5 +24V3_IL O DC24V Power source
6 REGCLN O DC0V/24V Registration clutch: On/Off
7 +24V3_IL O DC24V Power source
8 MIDCLN O DC0V/24V Conveying clutch: On/Off
9 +24V3_IL O DC24V Power source
10 DUCLN O DC0V/24V Duplex clutch: On/Off
YC6 1 +24V0 O DC24V Power source
Connector Pins Signal I/O Voltage Description
