PWBs ＞ Description for PWB
[CONFIDENTIAL]
2 +24V0_IL O DC24V Power source
YC7 1 CAS3 I DC0V/24V Cassette size switch: On/Off
2 CAS2 I DC0V/3.3V Cassette size switch: On/Off
3 CASSET - - Cassette size switch common signal
4 CAS1 I DC0V/3.3V Cassette size switch: On/Off
YC8 1 +24V3_IL O DC24V Power source
2 MPFSOLN O DC0V/24V MP solenoid: On/Off
YC9 1 +24V0_F1 O DC24V Power source
2 DHEATER O Drum heater: On/Off
YC10 1 +24V0 O DC24V Power source
2 FANRN O DC0V/24V Power source fan motor: On/Off
YC12 1 +3.3V3_F2 O DC3.3V Power source
2 GND - - Ground
3 PAPFULN I DC0V/3.3V Eject full sensor: On/Off
YC13 1 LIFTMOTOR O DC0V/5V Lift motor: On/Off
2 GND - - Ground
YC14 1 +3.3V_F2 O DC3.3V Power source
2 GND - - Ground
3 LSENS I DC0V/3.3V Lift sensor: On/Off
YC15 1 +24V3_IL_F5 O DC24V Power source
2 GND - - Ground
3 PLGDRN O DC0V/5V Polygon motor: On/Off
4 PLGRDYN I DC0V/3.3V Ready signal
5 POLCLK O DC0V/3.3V (pulse) Clock signal
YC16 1 +5.0V3_F1 O DC5V Power source
2 VDATA1P O LVDS Video data 1 signal (+)
3 VDATA1N O LVDS Video data 1 signal (-)
4 VDATA2P O LVDS Video data 2 signal (+)
5 VDATA2N O LVDS Video data 2 signal (-)
6 SAMPLEN1 O DC0V/3.3V Sample / hold signal 1
7 SAMPLEN2 O DC0V/3.3V Sample / hold signal 2
8 OUTPEN O DC0V/3.3V Laser enable
9 VCONT1 O Analog LD-1 Light volume adjustment
10 VCONT2 O Analog LD-2 Light volume adjustment
11 GND - - Ground
12 PDN I DC0V/3.3V (pulse) Main scanning synchronizing signal
13 +3.3V3_F2 O DC3.3V Power source
YC18 1 GND - - Ground
2 POWERSW I DC0V/3.3V Power source switch: On/Off
YC19 1 ENVSENSN I DC0V/3.3V Fuser pressure release sensor: On/Off
2 GND - - Ground
3 MISENS I Analog MC output signal
4 MHVCLK O DC0V/3.3V (pulse) MC clock signal
5 MACCNT O Analog MC AC control signal
6 MDCCNT O Analog MC DC control signal
7 HVCLK O DC0V/3.3V (pulse) DEV clock signal
YC19 8 BDCNT O Analog DEV DC control signal
Connector Pins Signal I/O Voltage Description
