Vacon 100 Applications Manual

Table 41: Preset frequency parameters
Index Parameter Min Max Unit Default ID Description
P3.3.3.11
Preset Frequency
Selection 1
DigIN
SlotA.5
420
A binary selector for
Preset speeds (0-7).
See parameters
P3.3.3.2 to P3.3.3.9.
P3.3.3.12
Preset Frequency
Selection 2
DigIN
Slot0.1
421
A binary selector for
Preset speeds (0-7).
See parameters
P3.3.3.2 to P3.3.3.9.
Table 42: Motor potentiometer parameters
Index Parameter Min Max Unit Default ID Description
P3.3.4.1
Motor Potentiometer
UP
DigIN
Slot0.1
418
FALSE = Not active
TRUE = Active. The
motor potentiometer
reference INCREASES
until the contact is
opened.
P3.3.4.2
Motor Potentiometer
DOWN
DigIN
Slot0.1
417
FALSE = Not active
TRUE = Active. The
motor potentiometer
reference DECREASES
until the contact is
opened.
P3.3.4.3
Motor Potentiometer
Ramp Time
0.1 500.0 Hz/s 10.0 331
The rate of change in
the motor
potentiometer
reference when it is
increased or decreased
with P3.3.4.1. or
P3.3.4.2.
P3.3.4.4
Motor Potentiometer
Reset
0 2 1 367
The reset logic for the
motor potentiometer
frequency reference.
0 = No reset
1 = Reset if stopped
2 = Reset if powered
down
PARAMETERS MENU VACON · 131
