NOTE!
When the sprockets are at the front side of the
machine, the machine will be moved to the opposite
direction as to above.
- The distance the travel levers/pedals are pulled
or pushed determines the travel speed of the
machine. That is, if the levers/pedals are pushed
or pulled fully, the machine will travel at the
maximum speed, provided that the high travel
speed has been selected and the engine RPM is
at full throttle position.
- The machine brakes are engaged automatically
when the travel controls are moved to the neutral
position. To reduce the travel speed, slowly return
the travel controls to the center (neutral) position.
- In cold weather, the travel function may be
heavier than normal due to the oil viscosity.
Left turn
1 When the sprockets are at the rear side of the
machine Push the right lever (D) forward, the RH
track rotates forward and the machine travels
forward as it turns to the left.
Pull the left lever (C) backward, the LH track
rotates in reverse and the machine travels
backward as it turns to the left.
2 When the sprocket is at the front side of the
machine Operate levers (C or D) in the opposite
direction as to above.
100
