Volvo EC140E - Lifting capacities

Lifting capacities
For North America
EC140E L without dozer
blade
H
5 ft 10 ft 15 ft 20 ft 25 ft Max. Reach
Max.
Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib ft
Boom: 4.6 m (15’ 1”)
Dipper arm: 2.1 m (6’ 11”)
Shoe: 600 mm (24”)
Counterweight: 2100 kg
(4630 Ib)
20 ft - - - - *7470 *7470 - - - - *7730 7710 15.77
15 ft - - - - *7600 *7600 - - - - *7850 5470 19.49
10 ft - - *13270 *13270 *9380 7950 7950 5160 - - 7130 4620 21.42
5 ft - - - - *11650 7490 7770 4990 - - 6710 4320 22.04
0 ft - - *12670 *12670 11680 7190 7620 4850 - - 6890 4410 21.46
-5 ft *11310 *11310 *20480 13010 11590 7110 - - - - 7830 4980 19.59
-10 ft - - *17740 13280 *11710 7270 - - - - *10660 6710 15.95
Boom: 4.6 m (15’ 1”)
Dipper arm: 2.5 m (8’ 2”)
Shoe: 600 mm (24”)
Counterweight: 2100 kg
(4630 Ib)
20 ft - - - - *6350 *6350 - - - - *7080 6600 17.49
15 ft - - - - *6740 *6740 *7080 5310 - - *7000 4920 20.90
10 ft - - *11370 *11370 *8570 8030 *7630 5190 - - 6520 4230 22.70
5 ft - - *16030 13570 *10980 7530 7770 4980 - - 6170 3970 23.28
0 ft - - *13890 12940 11670 7170 7580 4820 - - 6300 4030 22.74
-5 ft *10250 *10250 *20840 12870 11510 7030 7520 4760 - - 7030 4470 20.99
-10 ft *20220 *20220 *18770 13070 11610 7120 - - - - 9120 5730 17.66
Boom: 4.6 m (15’ 1”)
Dipper arm: 3.0 m (9’ 10”)
Shoe: 600 mm (24”)
Counterweight: 2100 kg
(4630 Ib)
20 ft - - - - - - - - - - *6250 5540 19.57
15 ft - - - - - - *6140 5360 - - *5830 4310 22.66
10 ft - - - - *7460 *7460 *6870 5190 - - *5800 3760 24.33
5 ft - - *15710 13840 *10010 7560 7750 4960 - - 5540 3540 24.87
0 ft - - *15160 12890 11630 7120 7520 4750 - - 5620 3570 24.37
-5 ft *8970 *8970 *20130 12650 11380 6910 7390 4630 - - 6170 3900 22.74
-10 ft *16640 *16640 *19640 12760 11400 6920 - - - - 7620 4790 19.72
-15 ft - - *15330 13220 - - - - - - *9920 7690 14.38
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 401
