Volvo EC140E - Optional pedal (straight travel); Optional pedal (Variable adjustable boom); Dozer blade lever (optional equipment)

6 Optional pedal (straight travel)
Position 1: Operating straight travel
Position 2: Lock the pedal
NOTICE
Make sure that the pedal is in locked position when
it is not used in order to prevent unwanted
manoeuvres.
Optional pedal (Variable adjustable boom)
Position 1: Operating variable adjustable boom
Position 2: Lock the pedal
NOTICE
Make sure that the pedal is in locked position when
it is not used in order to prevent unwanted
manoeuvres.
7 Dozer blade lever (optional equipment)
Position 1: Dozer blade lower
Position 2: Dozer blade raise
1
2
V1067112
V1068025
1
2
1
2
V1149038
102
Other controls
Controls
