Volvo EC140E - Engine; Engine, specifications; Carbon dioxide emissions

Engine
Engine, specifications
Designation D4J
Number of cylinders 4
Cylinder bore 101 mm (3.98 in)
Stroke 126 mm (4.96 in)
Displacement 4.04 litres (247 in³)
Injection order 1-3-4-2
Compression ratio 16.6:1
Power output at 33.3 r/s (2000 rpm) 90 kW (122 PS, 121 HP) SAE J1995 Gross
89 kW (121 PS, 119 HP) ISO 9249 / SAE J1349
Net
Maximum torque 566 Nm (58 kgf m, 417 lbf ft) at 1500 rpm
Low idle 950 rpm
High idle 2100 rpm
Carbon dioxide emissions
NOTE!
Only applicable to engine(s) quipped to meet the
legal requirements for exhaust emissions according
to EU Stage V.
The table below shows the value of the carbon
dioxide (CO
2
) emission determined from EU-type
approval testing of parent engine(s) in the warm
part of the Non Road Transient Test Cycle (NRTC).
Test cycle NRTC
Parent engine With B7 fuel
D4J, CO
2
(g/kWh) 737.6
Specifications
Engine 369
