Volvo EC140E - Manual release of travel brake

Manual release of travel brake
If it is impossible to operate the machine due to the
failure of the components in the track motor, the
travel brake should be released. Contact a qualified
service technician for detailed information.
1 Apply constant hydraulic pressure of 3.9 MPa
(40 kgf cm², 569 psi) at port (A) of the track motor
using external pressure source to keep the brake
released.
2 Connect a hydraulic hose between port (B) and
port (C) after removing plugs to move the
machine.
AC
B
V1108192
EC140E L
A Brake released port
B Pressure gauge port
C Pressure gauge port
C
B
V1099531
A
EC140E LM
A Brake released port
B Pressure gauge port
C Pressure gauge port
Operating instructions
Retrieving and towing 201
