Relays
No. Capacity Appliance / Circuit
RE3502 Relay Work light (Counterweight)
RE3608 Relay Lower wiper
RE3511 Relay Work light (Cab)
RE3611 Relay Horn
RE3507 Relay Work light
RE8701 Relay Air conditioner
RE4206 Relay Travel alarm
RE3508 Relay Work light (Boom)
RE3607 Relay Upper wiper
RE3702 Relay Spare relay
RE3701 Relay Spare relay
RE3102 Relay Main 2
RE3101 Relay Main 1
Fuses
No. Capacity Appliance / Circuit
FU01 10A Work light (Boom, Deck)
FU02 10A Horn
FU03 15A Water separator heater, Auto lubrication
FU04 - -
FU05 10A Spare
FU06 10A Travel alarm
FU07 15A Seat heater, Air suspended seat heater
FU08 10A Tiltrotator
FU09 15A Spare
FU10 10A Spare
FU11 10A Hydraulic option 3
FU12 - -
FU13 10A Rotating warning beacon
FU14 10A Cigarette lighter, Power socket (24V)
FU15 10A Spare
Specifications
Electrical system
371
