No. Capacity Appliance / Circuit
FU16 - -
FU17 10A Keypad
FU18 10A Work light (Cab)
FU19 15A Fuel filler pump
FU20 20A Auxiliary heater, Air conditioner
FU21 15A GPMECU (General Purpose Machine Electronic Control
Unit)
FU22 15A EMS (Engine Management System)
FU23 10A Work light (Counterweight)
FU24 15A Ignition switch, HMICU (Human Machine Interface Control
Unit), IC (Instrument Cluster)
FU25 10A WECU (Telematics ECU)
FU26 10A Wiper and washer
FU27 - -
FU28 15A Work light (Boom)
FU29 15A Spare
FU30 15A ACM (Aftertreatment Control Module)
FU31 10A Power outlet
FU32 10A Removable counterweight
FU33 15A Interior light, Audio, Power outlet
FU34 - -
FU35 25A Air compressor
FU36 20A Spare
FU37 15A Diesel Particulate Filter
